ANJCD513BPM Forming Tap (Blind) Metric 513B已售出0個The 513B is a French-brand forming (fluteless) tap made of powder-metallurgy HSS, ideal for chipless thread forming — produces stronger threads with continuous grain, ideal for ductile materials. Available in 18 sizes (thread dia 1~12, pitch 0.25~1.75, overall length 30~82mm, shank dia 3~8.5mm). A TiAlN coating offers high-temperature wear resistance. Suitable for machining carbon and alloy steel, stainless steel, workpiece hardness up to HRC35. French brand, consistent quality.
商品分類
標籤
Chipless Tapping
Thread Forming
Product Overview: Powder Metallurgy Fluteless (Form) Tap Blind Hole Metric – 513B Series
【Product Features & Why We Recommend It】
- French Brand Professional Quality: Originating from a professional French cutting tool brand with rigorous quality control — recommended for users with high demands on metric blind hole form tapping thread strength and tool durability.
- Blind Hole Form Tapping Dedicated Design: Features a fluteless (cold forging) tapping principle that forms threads through plastic deformation — dedicated specifically for metric blind hole tapping operations, completely eliminating chip generation and hole bottom chip accumulation issues, where the work-hardened thread surface achieves significantly higher strength than cut threads, making it the optimal choice for blind hole high-strength thread production.
- HSS-PM Powder Metallurgy High-Performance Substrate: Manufactured with powder metallurgy high-speed steel (HSS-PM), delivering extremely uniform carbide distribution, outstanding toughness, and wear resistance — recommended for long-duration stable blind hole form tapping of carbon steel and stainless steel, providing superior tool life compared to standard HSS and HSS-CO.
- TiAlN Premium Coating Enhancement: The surface is treated with TiAlN coating, providing outstanding heat resistance and oxidation resistance — recommended for blind hole tapping under high forming torque and elevated temperature conditions, maintaining outstanding wear resistance performance even at high cutting temperatures and significantly extending tool change intervals.
- Micro to Standard Diameter Full Coverage: Available in thread diameter 1–12mm and pitch 0.25–1.75mm across 18 specifications — recommended as the dedicated high-performance stock tool for carbon steel and stainless steel metric blind hole form tapping, covering all blind hole thread requirements from micro to standard diameters.
【Machining Applications & Uses】
- Primary Use: Metric precision blind hole form thread forming, high-strength blind hole threaded hole production, and NC machining center chip-free metric blind hole automatic tapping.
- Recommended Work Materials:
- P-Class (Carbon Steel / Alloy Steel): Structural steel, carbon steel, and alloy steel — recommended for hardness below HRC35, where HSS-PM combined with TiAlN coating delivers stable blind hole form tapping performance, with formed thread strength superior to cut threads, representing the core recommended application scenario for this series.
- M-Class (Stainless Steel): SUS304, SUS316, and other high-toughness stainless steel — the blind hole form tapping design completely eliminates continuous chip formation and hole bottom chip accumulation issues, while the TiAlN coating effectively suppresses cutting heat accumulation during the forming process, recommended for use with appropriate cutting fluid.
