ANVCD5BPFYatora General Purpose Spiral Point Tap UNF 5BPF已售出0個The UNF 5BPF is a French-brand spiral point tap made of HSS-EX, ideal for tapping through holes — its spiral point pushes chips forward for fast, clean threading. Available in 34 sizes (thread dia 1~9, pitch 12~64, thread length 3mm, overall length 42~125mm, shank dia 3~20mm). A TiN coating adds a hard golden film for better wear and anti-galling, extending tool life. Suitable for machining carbon and alloy steel, stainless steel, non-ferrous metals like aluminium and copper, workpiece hardness up to HRC40. French brand, consistent quality.
商品分類
Cutting ToolsTapSpiral Point Tap (for Through Holes)
Yatora General Purpose Spiral Point Tap UNF 5BPF
標籤
Product Overview: HSS Tiger General-Purpose Spiral Point Tap UNF – 5BPF Series
【Product Features & Why We Recommend It】
- French Brand Professional Quality: Originating from a professional French cutting tool brand with rigorous quality control — recommended for users with high demands on UNF American standard fine thread tapping accuracy, multi-material versatility, and tool consistency.
- HSS-EX Ultra-High Performance Substrate: Manufactured with HSS-EX ultra-high performance high-speed steel, with maximum machining hardness up to HRC40 — delivering superior hardness, toughness, and wear resistance compared to standard HSS and HSS-CO, recommended for high-demand applications requiring long-duration stable UNF fine thread tapping or machining of harder materials.
- Tiger General-Purpose Spiral Point Design: Features a Tiger (TIGER) general-purpose spiral point tap geometry optimized for versatility across multiple materials — pushing chips forward and out of the hole, recommended for UNF through-hole tapping of carbon steel, stainless steel, and non-ferrous metals, where the fine thread design provides higher thread strength and locking reliability compared to UNC coarse threads.
- TiN Coating Enhancement: The surface is treated with TiN coating, providing good wear resistance and heat resistance — recommended for continuous UNF fine thread tapping across various materials, effectively extending tool change intervals and suppressing cutting heat accumulation.
- UNF Fine Thread Specification Wide Coverage: Available in thread diameter 1–9 inches and pitch 12–64 TPI across 34 specifications — recommended as the most comprehensive general-purpose stock tapping tool for American UNF fine thread workpieces, precision machinery, or high-strength locking applications.
【Machining Applications & Uses】
- Primary Use: UNF American standard fine thread multi-material general-purpose through-hole tapping, precision machinery fine thread forming, and NC machining center UNF high-efficiency automatic tapping.
- Recommended Work Materials:
- P-Class (Carbon Steel / Alloy Steel): Structural steel, carbon steel, and alloy steel — recommended for hardness below HRC40, where HSS-EX combined with TiN coating delivers stable and long-lasting UNF fine thread tapping performance.
- M-Class (Stainless Steel): SUS304, SUS316, and other high-toughness stainless steel — the Tiger general-purpose geometry combined with HSS-EX substrate effectively addresses the work hardening and continuous chip formation challenges during fine thread tapping, recommended for use with appropriate cutting fluid.
- N-Class (Non-Ferrous Metals): Aluminum alloys, pure copper, brass, and other non-ferrous metals — the spiral point design ensures smooth chip evacuation for fine threads, preventing built-up edge from affecting UNF thread quality.
